Sequal Q86

Request free quote

Sequal Q86L - PHZ Square

  • 6-chamber frame with 86mm depth
  • The core of the profile is made of a high-strength RAU-FIPRO composite fiber material: exceptional stability and maximum torsional stiffness
  • Thermal modules that allow you to optimize insulation
  • 6-chamber non-coplanar stepped door with 86mm depth
  • High quality and weather resistant EPDM gaskets
  • Linear surfaces with slightly rounded edges to ensure visual spaces even with minimal openings. Small footprint to let in more light
  • Structure in evo-compatible and recyclable PVC because it is lead-free, replaced by the calcium-zinc alloy, an alloy with high eco-compatibility
  • Special median gasket system with 3 gaskets: it allows to obtain a great airtightness
  • 66mm deep glazing cavity that allows the use of double glazing with thickness up to 53mm
  • Square glazing bead as standard
  • Multi-matic hardware with 4 anti-burglary points as standard
  • Smooth inclined groove: simple cleaning, facilitates water drainage

Sequal Q86L - Square

  • 6-chamber frame with 86mm depth
  • The core of the profile is made of a high-strength RAU-FIPRO composite fiber material: exceptional stability and maximum torsional stiffness
  • Reinforcements in galvanized steel with optimized dimensions to ensure maximum static performance
  • 6-chamber non-coplanar stepped door with 86mm depth
  • High quality and weather resistant EPDM gaskets
  • Linear surfaces with slightly rounded edges to ensure visual spaces even with minimal openings. Small footprint to let in more light
  • Structure in evo-compatible and recyclable PVC because it is lead-free, replaced by the calcium-zinc alloy, an alloy with high eco-compatibility
  • Median gasket system with 3 gaskets: it allows to obtain a great airtightness
  • 66mm deep glazing cavity that allows the use of double glazing with thickness up to 53mm
  • Square glazing bead as standard
  • Multi-matic hardware with 4 anti-burglary points as standard
  • Smooth inclined groove: simple cleaning, facilitates water drainage

Sequal Q86 P97 - Square

  • 6-chamber frame with 86mm depth
  • The core of the profile is made of a high-strength RAU-FIPRO composite fiber material: exceptional stability and maximum torsional stiffness
  • Median gasket system with 3 gaskets: it allows to obtain a great airtightness
  • 6-chamber non-coplanar stepped door with 86mm depth
  • High quality and weather resistant EPDM gaskets
  • Linear surfaces with slightly rounded edges to ensure visual spaces even with minimal openings. Small footprint to let in more light
  • Aluminum threshold with thermal break
  • 66mm deep glazing cavity that allows the use of double glazing with thickness up to 53mm
  • 66mm deep glazing cavity that allows the use of double glazing with thickness up to 53mm
  • Square glazing bead as standard
  • Multi-matic lock with 5 anti-burglary points as standard

Sequal Q86 R40 - Square

  • 6-chamber frame with 86mm depth
  • The core of the profile is made of a high-strength RAU-FIPRO composite fiber material: exceptional stability and maximum torsional stiffness
  • 6-chamber non-coplanar stepped door with 86mm depth
  • High quality and weather resistant EPDM gaskets
  • Linear surfaces with slightly rounded edges to ensure visual spaces even with minimal openings. Small footprint to let in more light
  • Structure in evo-compatible and recyclable PVC because it is lead-free, replaced by the calcium-zinc alloy, an alloy with high eco-compatibility
  • Special median gasket system with 3 gaskets: it allows to obtain a great airtightness
  • 66mm deep glazing cavity that allows the use of double glazing with thickness up to 53mm
  • Square glazing bead as standard
  • Multi-matic hardware with 4 anti-burglary points as standard
  • Smooth inclined groove: simple cleaning, facilitates water drainage
